Whadda
VM204
EAN: 5410329732943

Velleman Ethernet 4 Channel Relay Module VM204

  • 1-5 Days
  • Description
  • More Details
New for December 2015

 tick  Module: Pre-assembled

new

 New - Now Available

The VM204 is an Ethernet controlled board with 4 relay outputs, 4 digital inputs and 1 analogue input.
It can send e-mail notifications when the status of an input changes and features an embedded webserver. Free apps are available for Android® and iOS®.
  • power supply: 5 Vdc power supply needed (min. 500 mA) via USB B connector
  • outputs: 4 no relay outputs (230 VAC / 5 A rated)
  • Ethernet: 100 Mbit
  • inputs:
    • 4 digital inputs (open collector compatible)
    • 1 analog input (6 V max.)
  • ports:
    • UART port avaiable
    • SPI port available



pdf

  Data Sheet

zip

  Software

 utube

  Software
